Nominal Cross sectional area

mm²

Conductor Number x diameter of wire

mm

Minimum

Radial thickness of

Nominal overall diameter

mm

Maximum

current rating

A

Approx. Net weight

Kg/

standard

length

kg

Standard

delivery

length

m

Delivery form

insulation

sheath

In pipe

In air

mm

mm

0.5RW

1x0.80

0.6

-

2.0

5

8

9.1

1000

Coil

1.0RW

1x1.13

0.6

-

2.3

9

15

1.5

100

Coil

1.5RW

1x1.38

0.6

-

2.6

14

23

1.93

100

Coil

2.5RW

1x1.78

0.7

-

3.2

19

31

3.1

100

Coil

4RW

1x2.25

0.8

-

3.9

24

40

4.8

100

Coil

4RS

7x0.85

0.8

-

4.2

27

44

4.8

100

Coil

6RW

1x2.76

0.8

-

4.4

31

51

6.8

100

Coil

6RS

7x1.04

0.8

-

5.1

35

55

6.8

100

Coil

10RS

7x1.35

1.0

-

6.1

42

70

12.0

100

Coil

16RS

7x1.70

1.0

-

7.1

55

91

18.0

100

Coil

25RS

7x2.12

1.2

-

8.8

73

122

28.2

100

Coil

35RS

7x2.50

1.2

-

10.0

91

152

38.4

100

Coil

50RS

7x1.78

1.4

-

11.7

112

187

516

1000

R10

70RS

19x2.12

1.4

-

13.5

141

235

726

1000

R12

Note:

1. Maximum permissible conductor temperature under service condition is taken at 70⁰C.
2. Maximum current rating in ground is considered at ground temperature of 35⁰C.
3. Maximum current rating in air is considered at a temperature of 40⁰C.

RW = Round Solid Wire (Conductor)

 RS = Round Stranded Conductor
